Technical data
Weight: 2 . 3 kg
Design heighe : 2 6 0mm
Deflection (Hight min) : 1 80mm
Deflection (Hight max) : 4 1 5mm
Working stroke : 2 3 5 mm
Measurement d max : 2 9 5 mm
Space required : 3 1 0 mm
Loading cap. at 1.0bar : 3 . 5 k N
Loading cap. at 9.5bar : 4 0 . 0 kN
CONTITECH : 916 N1 M.A.N. : 81.43601.0126
GOODYEAR : 9015 :81.43601.0105
PHOENIX : 1 F 21 C-5 :81.43601.0102
TAURUS : B 154 :81.43601.0100
DUNLOP FR : D12S05 :81.43601.0097
:81.43601.0095
Cross section view
E916
OEM Information
